Page 62
58
Single-Section PTO Pumps
Great Plains Manufacturing, Inc.
401-885M
2014-06-16
401-849A and 411-167A Flow Control Hydraulics
401-849A and 411-167A
Hose Identification
Hydraulic Connections
Callout
Hose
Hose Description
Reservoir Outlet to Pump Inlet
841-848C
HH1R4 144 1 5/16FJIC
Pump Outlet to Valve Port P
811-807C
HH1/2R2 120 3/4FJIC
Valve Port M to Fan Motor Inlet B
811-059C
HH1/2R2 080 3/4FJIC
Tee at Fan Motor Outlet A
811-073C
TE 3/4MJIC 3/4MJIC 3/4FJIC
Valve Port T to Fan Motor Tee
811-059C
HH1/2R2 080 3/4FJIC
Fan Motor Tee to Cooler Inlet
811-268C
HH1/2R2 048 3/4FJIC
Cooler Outlet to Oil Filter
811-268C
HH1/2R2 048 3/4FJIC
818-
24
0C
Re
v. A
To a
void Injur
y or
Mac
hine Dama
ge:
·Operate onl
y with
1000 rpm PT
O
CAUTION
858
-00
5C
All
d
riv
el
ine guar
ds,
tr
actor
an
d eq
uipm
ent
sh
ie
lds
in
p
la
ce
PT
O p
um
p
ass
em
bly s
ec
ur
ely
attached with
torq
ue a
rm
an
d ch
ain
RO
TA
TING DRIVELINE -
CONT
AC
T CAN CA
USE DEA
TH
KEEP A
W
AY
!
DO NO
T OPERA
TE
WITHOUT
-
DANGER
Figure 65:
401-849A and 411-167A Hydraulic Hose Routing
34675
36312
194
222
204
194
P
T
M
B
A
841-848C
811-807C
811-268C
811-268C
188
811-073C
186
811-059C
222
204
186
188
186
194
194
