Re-Install RPM Sensor Bracket
If there is no sensor bracket, or if not installing a
401-956A fan motor update, continue at “Install Fan
Cooler” on page 37.
Refer to Figure 37
56. Select one saved:
401-537D DJ FAN SENSOR MOUNT BRKT
and two sets saved:
802-005C HHCS 1/4-20X1 GR5
804-006C WASHER LOCK SPRING 1/4 PLT
804-075C WASHER FLAT 1/4 USS PLT
With the bend in the bracket toward the impeller
bushing, install the bracket at the top and bottom
holes
, using the bolts , lock washers and
flat washers .
Route any sensor lead present out the previously
existing hole in the fan screen.
If installing a fan motor update only, continue at step 66
on page 39.
21
28
31
17
51c
b
b
b
a
b
a
U
D
F
B
L
R
Figure 37:
Re-Install Sensor Bracket
34631
17
21
28
31
17
a 21 28
