879a and 411-168a flow control hydraulics – Great Plains PTO Kits Single-Section User Manual
Page 63
Great Plains Manufacturing, Inc.
Appendix A - Installation
59
2014-06-16
401-885M
401-879A and 411-168A Flow Control Hydraulics
Continue at “Charge and Test” on page 64.
401-879A and 411-168A
Hose Identification
Hydraulic Connections
Callout
Hose
Hose Description
Elbow at Reservoir Outlet
841-815C
EL 1 5/16FJIC 1 5/16MJIC
Reservoir Outlet to Pump Inlet
841-847C
HH1R4 90 1 5/16FJIC
Pump Outlet to Valve Port P
811-773C
HH1/2R2 066 3/4FJIC
Valve Port M to Fan Motor Inlet B
811-269C
HH1/2R2 036 3/4FJIC
Fan Motor Outlet A to Valve Port T
841-196C
HH1/2R2 024 3/4FJIC
Valve Port T to Cooler Inlet
811-268C
HH1/2R2 048 3/4FJIC
Cooler Outlet to Oil Filter
811-268C
HH1/2R2 048 3/4FJIC
818-
240
C Re
v. A
To a
void Injur
y or
Mac
hine Dama
ge:
·Operate onl
y with
1000 rpm PT
O
CAUTION
85
8-
005
C
All dr
iveline gua
rds
, tr
actor
and
e
qu
ip
me
nt shiel
ds in place
PT
O
pu
mp
a
sse
mb
ly securely
att
ached with
torque ar
m and chain
RO
TA
TING DRIVELINE -
CONT
AC
T CAN CA
USE DEA
TH
KEEP A
W
AY
!
DO NO
T OPERA
TE
WITHOUT
-
DANGER
Figure 66:
401-879A and 411-168A Hydraulic Hose Routing
34669
36312
194
221
203
195
215
P
T
T
M
B
A
841-847C
811-268C
220
841-815C
194
811-773C
811-269C
841-196C
811-268C
220
221
203
195
215
194
194
