5.07 Configuration at Front Panel Menu
The INT06 can also be programmed at the front panel in menu "Extras, Robot Interface". The eight analog
inputs can be enabled or disabled. So it is not necessary to open the machine and set the DIP switches. If there
are not enough digital outputs available at the robot control to select a welding program, it is possible to select
three different pre-defined welding programs with only two digital outputs. Those welding programs can be
set at menu items "ProgIn1" to "ProgIn3". The selection of these welding programs is made over the digital
inputs 1 and 2 (pin 1 and 2).
Menu Item Pin No. Setting Description
On analog input is enabled (corresponds with DIP switch 1 set to “ON”) Opt01(AnalogIn1) 23
Off analog input is disabled
On analog input is enabled (corresponds with DIP switch 2 set to “ON”) Opt02(AnalogIn2) 24
Off analog input is disabled
On analog input is enabled (corresponds with DIP switch 3 set to “ON”) Opt03(AnalogIn3) 25
Off analog input is disabled
On analog input is enabled (corresponds with DIP switch 4 set to “ON”) Opt04(AnalogIn4) 26
Off analog input is disabled
On analog input is enabled (corresponds with DIP switch 5 set to “ON”) Opt05(AnalogIn5) 27
Off analog input is disabled
On analog input is enabled (corresponds with DIP switch 6 set to “ON”) Opt06(AnalogIn6) 28
Off analog input is disabled
On analog input is enabled (corresponds with DIP switch 7 set to “ON”) Opt07(AnalogIn7) 29
Off analog input is disabled
On analog input is enabled (corresponds with DIP switch 8 set to “ON”) Opt08(AnalogIn8) 30
Off analog input is disabled
On program selection is enabled (corresponds with DIP switch 9 set to “ON”) Opt09(ProgSelect)
Off program selection is disabled
On operating mode selection is enabled (corresponds with DIP switch 10 set to “ON”) Opt10(OperMode)
Off operating mode selection is disabled
On “robot mode” is active (corresponds with the signal “set extern”) Opt11(Setextern)
Off “manual hand mode” is active
On When using job selection (tiptronic mode) it is possible during the welding, to change enabled
parameters over the analog inputs. For example during the welding process the welding current can
be altered with the control voltage at the analog input 1 [Opt01(AnalogIn1) must be set to “ON”]
Opt12(Job+Analog)
Off Normal tiptronic mode, all welding parameters are stored in the job and can’t be changed over the
analog inputs.
ProgIn1 = Prog (0-99) Assignment of a welding program
welding program no. (0-99) set as program 1
ProgIn2 = Prog (0-99) Assignment of a welding program
welding program no. (0-99) set as program 2
ProgIn3 = Prog (0-99) Assignment of a welding program
welding program no. (0-99) set as program 3
