POWERMASTER 400SP, 500SP AUTOMATION
March 16, 2007 5-9
Other Analog Parameters
Designation Description Signal Function
0V 0 sec. pre gas time Control voltage 0-10V for the pre gas time.
10V DC 10 sec.
0V 20% gas post time Control voltage 0-10V for the gas post time.
10V DC 300%
0V 5% of welding current twinpulse current change Control voltage 0-10V for the twinpulse current change.
The operating mode twinpulse must be active. 10V DC 50% of welding current
0V 20% twinpulse relation Control voltage 0-10V for the twinpulse relation.
The operating mode twinpulse must be active. 10V DC 80%
0V 20% of programmed value wire burnback time Control voltage 0-10V for the wire burnback time.
10V DC 300% of programmed value
0V 20% of programmed value inductor effect Control voltage 0-10V for the inductor effect.
10V DC 200% of programmed value
