POWERMASTER 400SP, 500SP AUTOMATION
March 16, 2007
5-5
5.05 Robot Interface INT06 PC Board Schematic
X2
LED2
X1
LED15
LED1
X3
X4
X5
LED5
LED18
LED17
LED3
LED16
LED4
650.5282.x INT06 RP367/1 D00.0110.0-00
Art # A-07940
Connector Description
X1 CAN
connector
X2 Internal programming connector
X3 Flat
ribbon connector to 42 pin Harting socket (digital and analog inputs)
X4 Flat
ribbon connector to 42 pin Harting socket (digital in- and outputs)
X5
Additional analog outputs (optional)
Robot Interface PC Board Connectors
