INTRODUCTION & DESCRIPTION 10 Manual 0-2023
2.03 Specifications & Design
Features
A. Weld Sequencer Enclosure
1. Input Power
115/230VAC, 1 Amp, 50/60 Hz
2. Control Circuit Output
28 VAC
3. Current Control
Up to 24 VDC using RP1 Control remote pendant
or some other external device.
4. Contactor Control
28 V control circuit using RP1 Control remote pen-
dant or some other external device.
5. Control Console or Power Supply Control
Control is via 10' control cable.
6. Auxiliary Connections
Relay contacts and terminal connector provided
for auxiliary input/output signals (wire feeders,
motion controls, etc.).
7. Housing Capabilities
WT1 and/or GS1; WT1 and/or CS1 and/or CP1
NOTE
For a complete Sequencer Assembly, the Enclosure
Expansion must be added on top of the Weld Se-
quencer Enclosure to accommodate CS1 and CP1
modules. Also, the enclosure expansion is required
when WT1 or GS1 is used with either CS1 or CP1.
8. Dimensions (W x H xD)
15 inches (381 mm) x 11 inches (279 mm) x 16-3/4
inches (425 mm)
With Enclosure Expansion height dimension is 18
inches (457 mm)
9. Weight
24.5 lbs (11.62 kg).
With Enclosure Expansion weight is 30 lbs
(14.23kg)
B. GS1 Gas Slope (Plasma)
1. Input Power
28 VAC from Weld Sequencer Enclosure
2. Plasma Gas Range
Min 0.5 - 3 scfh (0.25 - 1.4 lpm)
Max 2 - 7 scfh (1 - 3.3 lpm) @ 30 psi (2 bar)
3. Weight
9 lbs (4.05 kg)
C. CS1 Current Slope
1. Input Power
28 VAC from Weld Sequencer Enclosure
2. Weight
4 lbs (1.8 kg)
D. CP1 Pulser
1. Input Power
28 VAC from Weld Sequencer Enclosure
2. Pulse Rate
0.5 - 20 pulses/sec
3. Weight
3.5 lbs (1.58 kg)
E. WT1 Weld Timer
1. Input Power
28 VAC from Weld Sequencer Enclosure
2. Timing Control
Adjustable from 0.1 to 999.9 seconds
3. Weight
2.5 lbs (1.12 kg)
CAUTION
When using CS1 or CP1 with a power source other
than the Thermal Arc PS30A, the remote control
circuit must be 0 to +24 vdc and of a solid state
design.
