8 E-flite AT-6 Texan ARF Assembly Manual
Stabilizer Installation
Required Parts
Stabilizer (right and left) 3mm x 10mm self-tapping screw
(2)
Stabilizer tube Nylon clevis (3)
Clevis retainer (3) 1-inch (25mm) tail wheel
1/16-inch wheel collar w/setscrew
20
7 /
8
-inch (530mm) pushrod wire (2)
21 3 / 4
-inch (553mm) pushrod wire
Required Tools and Adhesives
Drill Drill bit: 5/64-inch (2mm)
Phillips screwdriver: #1 Threadlock
Hex wrench (included with kit)
 1. Slide the stabilizer tube all the way into the stabilizer.
 2. Use a drill and 5/64-inch (2mm) drill bit to drill
through the hole in the bottom of the stabilizer and into
the stabilizer tube.
 3. Secure the tube using a 3mm x 10mm self-tapping
screw and #1 Phillips screwdriver.
