2 E-flite AT-6 Texan ARF Assembly Manual
Introduction
E-flite’s AT-6 25e ARF is a superb scale replica of the legendary
“Texan” trainer used by the U.S.—and its allies—from WWII
through the late 1960s. It features a level of scale detail that
is exceptional for an ARF of this size. You get all this realism
without having to spend weeks of building, covering and
painting. Just about everything has been done for you before
you even open the box. All that’s left to do is a few hours of
final assembly and radio installation. When you’re done, you’ll
have a fantastic flying, scale warbird your friends will swear
you scratch-built yourself.
Platinum Series Statement
Our Platinum Series delivers superior, enhanced features and
meticulous attention to detail. The symbol on this kit is your
assurance of excellence and one more way that E-flite brings
you the most advanced electric flight experience.
Using the Manual
This manual is divided into sections to help make assembly
easier to understand, and to provide breaks between each
major section. In addition, check boxes have been placed next
to each step to keep track of each step completed. Steps with
a single circle () are performed once, while steps with two
circles ( ) indicate that the step will require repeating, such
as for a right or left wing panel, two servos, etc.
Remember to take your time and follow the directions.
Table of Contents
Specifications ...................................................................... 1
Introduction ......................................................................... 2
Using the Manual ................................................................ 2
Contents of Kit/Parts Layout ................................................. 3
Required Radio Equipment ................................................... 3
Important Information About Motor Selection ........................ 4
Outrunner Setup .................................................................. 4
Optional Accessories ........................................................... 4
Required Tools and Adhesives .............................................. 4
Notes Regarding Servos and ESC ........................................ 5
Note on Lithium Polymer Batteries ........................................ 5
Warning ............................................................................. 5
Warranty Information ...................................................... 5–7
Safety, Precautions, and Warnings ....................................... 7
Stabilizer Installation ........................................................... 8
Motor Installation .............................................................. 12
Main Radio Installation ...................................................... 16
Aileron Servo Installation ................................................... 20
Flap Servo Installation ....................................................... 24
Fixed Landing Gear Installation .......................................... 28
Retractable Landing Gear Installation ................................. 30
Power System Installation ................................................... 37
Wing Installation ............................................................... 39
Basic Cockpit and Accessories ........................................... 42
Optional Scale Cockpit Installation ..................................... 44
Control Throws .................................................................. 48
Range Test Your Radio ....................................................... 48
Center of Gravity .............................................................. 49
Preflight ............................................................................ 49
Flying Your AT-6 Texan ARF ............................................... 50
2007 Official AMA National Model Aircraft Safety Code ... 51
