REIGN™ 12-24V BUTTON/FULL SLIDE DIMMER SWITCH
Troubleshooting
Fixture does not illuminate
• Verify the system is wired correctly & ensure polarities are correct.
• Ensure the driver and fixture have the same voltage specifiations (12V & 12V, or 24V & 24V).
Fixture illuminates, dimmer controls are
unresponsive
• Verify the following connections &ensure polarities are correct: Driver Output is connected
to Dimmer Input; Dimmer Output is connected to LED Load. If the driver is connected to the
Dimmer Input than the dimmer controls will not function properly.
Fixture is consistently flashing or flickering
• Ensure no more than a single dimmer is attached to each driver output.
• Verify a compatible constant voltage driver is installed.
• Ensure a compatible constant voltage dimmable fixture is installed.
Fixture is inconsistently flashing or flickering • Verify all connections are properly secured. Ensure all accessories are properly connected.
Fixture is slowly flashing
• Ensure driver is not overloaded. An overloaded driver will cause the internal auto-reset of the
driver to trip repeatedly.
Shift in brightness of fixture array
• Verify the appropriate size wire gauge (AWG) has been installed. See the ‘Tools & Resources’
page at www.DiodeLED.com for Voltage Drop Charts.
• Ensure fixture length is not exceeding maximum run limit.
Driver is buzzing
• Verify the constant voltage driver is compatible with compatible with PWM controls. See
the driver specification sheet and check the ‘Dimmability’ specification.
Prior to troubleshooting, ensure a compatible system is installed. Verify compatible fixtures, drivers, controls and additional components were
specified correctly.
Additional Resources
Visit the online product page at www.DiodeLED.com for additional product specifications & warranty information.
• REIGN 12-24V Button Slide Dimmer Switch Specification Sheet
For full specifications.
• REIGN 12-24V Full Slide Dimmer Switch Specification Sheet
For full specifications.
• Voltage Drop Charts
Use to specify appropriate wire gauge for installation. Available at the ‘Tools & Resources’ page at www.DiodeLED.com.
