WINCUEPRONEWS USER GUIDE
VERSION 1.30B515
129
QTV 1998
C3 Laptop and I.M.T. Box Wiring Diagram (UK)
Powering the I.M.T. Box: -
Choose between AC Mains power supply and 12 volts DC
Genlock
Input
On Camera Units
Laptop Computer
SCSI
Port
PCMCIA
SCSI Card
AC
~
12 v
I.M.T. Scroll Control
