Rockwell Automation DeviceLogix System User Manual User Manual
Page 57
Publication RA-UM003B-EN-P - February 2010
57
Navigate the Function Block Editor Interface Chapter 2
Move/Logical Category Toolbar
Move/Logical Category Toolbar
Function
Description
AND Instruction
Not AND
Instruction
OR
Instruction
Not OR Instruction
Exclusive OR
Instruction
Exclusive Not OR
Instruction
NOT Instruction
Set Latch Instruction
Reset Latch Instruction
