130 Publication RA-UM003B-EN-P - February 2010
Chapter 6 Navigate the New Ladder Editor Interface
Standard Toolbar
Tabbed Instruction Toolbar
The ladder element toolbars include:
• Bit Element
• Process Element
• Filter Element
• Select/Limit Element
• Statistical Element
• Timer/Counter Element
Function Description
Sends the ladder logic to a printer.
Removes the selected ladder element.
Duplicates the selected content to save it in the clipboard.
Removes the saved content in the clipboard and puts the content
in the new Ladder Editor where your cursor is resting.
Cancels the last action.
Performs again the previously cancelled action.
Increases (make larger) the view of the configuration. You lose
view of part of the configuration pane of the new Ladder Editor
when you use this function.
Decreases (make smaller) the view of the configuration. You see
more of the configuration pane of the new Ladder Editor when
you use this function.
Confirms that the logic that you configured is valid.
Toggles between working in the Edit mode and not working in
the Edit mode. In the Edit mode, you can make changes to the
Logic. You must exit the Edit mode to download the logic to the
device.
