Publication RA-UM003B-EN-P - February 2010 121
Create Logic in the Old DeviceLogix Ladder Editor Chapter 5
• Select Yes - the logic does not continue to run in the device and
new logic is downloaded to the device. When the download is
complete, you are asked if you want to start the logic running
again. If you:
– Select No - the online toolbar displays Logic Enable Off.
– Select Yes - the online toolbar displays Logic Enabled On; the
old Ladder Editor is animated. The message Not Saved
displays in the status bar until you exit the Ladder Editor and
save the new configuration.
Change the Value of Timers and Counters
When working in the online mode, it is possible to change the preset
and accumulator values of timers and counters.
To change the value:
1. Double click on the value you want to change.
2. Enter the new value into the box.
3. Press the Enter key.
The new value takes effect immediately. If you change a preset value,
remember to save the configuration the next time you exit the old
Ladder Editor.
Enable and Disable Logic
Logic Enable On
To cause the device to start processing the stored logic configuration:
Click Communications > Logic Enable On.
TIP
Note that you can use the edit mode icon on the standard
toolbar to enter edit mode.
You can use the download icon on the online toolbar to
download logic to the device.
