3-16 DBT Reach Drive User Manual
Sets the frequency the drive will output at Break Voltage (71).
Selects the units to be used for all speed related parameters. Options 0 and 1 indicate
status only. Options 2 and 3 will convert and/or configure the drive for that selection.
Convert Hz (2) = Converts all speed based parameters to Hz and changes the value
proportionately (i.e. 1800 RPM = 60 Hz).
Convert RPM (3) = Converts all speed based parameters to RPM and changes the
value proportionately.
Selects the source for motor speed feedback. Note that all selections are available
when using Process PI.
72 Break Frequency
Range: 0.0 to Maximum Freq [0.1 Hz]
Default: Motor NP Freq x 0.25
Access: 2 Path: Motor Control>Volts per Hertz
See also: 53, 71
79 Speed Units
Range: 0 = Hz
1 = RPM
2 = Convert Hz
3 = Convert RPM
Default: 0 = Hz
Access: 0 Path: Speed Command>Spd Mode & Limits
See also:
80 Feedback Select
Range: 0 = Open Loop
1 = Slip Comp
2 = Reserved
3 = Encoder
4 = Reserved
5 = Simulator
Default: 0 = Open Loop
Access: 2 Path: Speed Command>Spd Mode & Limits
See also: 53, 152, 412
