542 encdlss vlt comp, 543 excitation ki, 544 excitation kp – Rockwell Automation Liqui-Flo DBT Reach Drive User Manual
Page 176: 545 ln phaseloss lvl
3-150
DBT Reach Drive User Manual
Voltage used to compensate for long cables attached to inverter and motor. Identified
during autotune for Encoderless FVC.
Integral gain for current regulator for excitation of Flying start.
Proportional gain for current regulator for excitation of Flying start.
Input phase loss detection (level).
542
Encdlss Vlt Comp
Range:
0 to 115 [1]
Default:
6.1
Access:
2
Path: Utility>Diag-Vector Cnt
See also:
543
Excitation Ki
Range:
0 to 32767 [1]
Default:
44
Access:
2
Path: Utility>Diag-Vector Cnt
See also:
544
Excitation Kp
Range:
0 to 32767 [1]
Default:
1800
Access:
2
Path: Utility>Diag-Vector Cnt
See also:
545
ln Phaseloss Lvl
Range:
10 to 1000 [1]
Default:
325
Access:
2
Path: Utility>Diag-Vector Cnt
See also:
