Parameter Descriptions 3-103
Selects the value that the mask [Dig Out Mask (394)] will be applied to.
Sets the mask that is applied to the selected value in Dig Out Param (393). A bit
(AND/OR) is applied. The bit is selected by the Digital Outx Sel (380, 384,388). All bits
with zeros in the mask are ignored.
393 Dig Out Param
Range: 0 = PI Config
1 = PI Status
2 = Drive Sts 1
3 = Drive Sts 2
4 = DriveAlarm1
5 = DriveAlarm2
6 = StartInhibit
7 = Digln Status
8 = DrvSts1Flt
9 = DrvSts2Flt
10 = AlrmSts1Flt
11 = AlrmSts2Flt
12 = LogicCmdRslt
13 = Stop Owner
14 = Start Owner
15 = Jog Owner
16 = Dir Owner
17 = Ref Owner
18 = Accel Owner
19 = Decel Owner
20 = FltRst Owner
21 = MOP Owner
22 = Local Owner
23 = Limit Status
24 = PortMaskAct
25 = WriteMaskAct
26 = LogicMaskAct
27 = TorqProvCnfg
28 = TorqProvSet
29 = TorqProvSts
30 = Profile Sts
31 = Profile Cmd
Default: 0 = PI Config
Access: 2 Path: Inputs & Outputs>Digital Outputs
See also: 394
394 Dig Out Mask
Range: See figure 3.37
Default: See figure 3.37
Access: 2 Path: Inputs & Outputs>Digital Outputs
See also: 393
