3-88 DBT Reach Drive User Manual
Selects the source of the value that drives the analog output.
Table 3.3 – Analog Out1/2 Sel
Options
Analog Out1/2 Lo Value
Analog Out1/2 Hi P.341 = Signed P.341 = Absolute
0 = Output Freq -Maximum Speed 0 Hz + Maximum Speed
1 = Command Spd -Maximum Speed 0 Hz/RPM + Maximum Speed
2 = Output Amps 0 Amps 0 Amps 200% Rated
3 = Torque Amps -200% Rated 0 Amps 200% Rated
4 = Flux Amps 0 Amps 0 Amps 200% Rated
5 = Output Power 0 kW 0 kW 200% Rated
6 = Output Volts 0 Volts 0 Volts 120% Rated Input Volts
7 = DC Bus Volts 0 Volts 0 Volts 200% Rated Input Volts
8 = PI Reference -100% 0% 100%
9 = PI Feedback -100% 0% 100%
10 = PI Error -100% 0% 100%
11 = PI Output -100% 0% 100%
12 = %Motor OL 0% 0% 100%
13 = %Drive OL 0% 0% 100%
14 = CommandedTrq -800% Rated 0% 800% Rated
15 = MtrTrqCurRef -200% Rated 0% 200% Rated
16 = Speed Ref -Maximum Speed 0 Hz/RPM + Maximum Speed
17 = Speed Fdbk -Maximum Speed 0 Hz/RPM + Maximum Speed
18 = Pulse ln Ref -25200.0 RPM 0 Hz/RPM + Maximum Speed
19 = Torque Est -800% 0% 800%
20 = Scale Block 1 0% 0% 100%
21 = Scale Block 2 0% 0% 100%
22 = Scale Block 3 0% 0% 100%
23 = Scale Block 4 0% 0% 100%
24 = Param Cntl 0% 0% 100%
25 = SpdFb NoFilt 0% 0% 100%
