518 host dac enable, 523 bus utilization, 524 pwm type select – Rockwell Automation Liqui-Flo DBT Reach Drive User Manual
Page 171
Parameter Descriptions
3-145
Reserved. Do not adjust.
Reserved. Do not adjust.
Sets the drive output voltage limit as a percentage of the fundamental output voltage
when operating in 6 step mode. Values above 95% increase harmonic content and
jeopardize control stability. This output voltage limit is strictly a function of input line
and resulting bus voltage.
Allows selection of active PWM type. A value of 0 is default and results in a change of
PWM method at approximately 2/3 of rated motor frequency. If this is unacceptable for
harmonic or audible reasons, a value of 1 disables the change.
518
Host DAC Enable
Range:
0 to 1 [1]
Default:
0
Access:
2
Path: Utility>Diag-DACS
See also:
519
520
521
522
DAC55-A
DAC55-B
DAC55-C
DAC55-D
Range:
0 to 7432 [1]
Default:
0
Access:
2
Path: Utility>Diag-DACS
See also:
523
Bus Utilization
Range:
85.0 to 100.0% [0.1%]
Default:
95.0%
Access:
2
Path: Utility>Diag-Motor Cntl
See also:
524
PWM Type Select
Range:
0 to 1 [1]
Default:
0
Access:
2
Path: Utility>Diag-Motor Cntl
See also:
