Parameter Descriptions 3-9
Selects the output frequency below which the motor operating current is derated. The
motor thermal overload will then generate a fault at lower levels of current.
Sets the amps threshold for motor overload fault.
Motor FLA x OL Factor = Operating Level
Defines the number of poles in the motor.
Sets the method of motor control used in the drive.
Important: “FVC Vector” mode with encoder feedback requires autotuning of the
motor, both coupled and uncoupled to the load. Being coupled to the load
will determine inertia (preferably lightly loaded). Total Inertia (450) will
have to be estimated if uncoupled for tuning of the speed loop or
separately adjust Ki (445) and Kp (446).
Sensrls Vect = Maintains consistent magnetizing current up to base speed. Voltage
increases as a function of load.
47 Motor OL Hertz
Range: 0.0 to Motor NP Hz [0.1 Hz]
Default: Motor NP Hz/3
Access: 2 Path: Motor Control>Motor Data
See also: 42, 220
48 Motor OL Factor
Range: 0.20 to 2.00 [0.1]
Default: 1.00
Access: 2 Path: Motor Control>Motor Data
See also: 42, 220
49 Motor Poles
Range: 2 to 40 [1 Pole]
Default: 4
Access: 0 Path: Motor Control>Motor Data
See also:
53 Motor Cntl Sel
Range: 0 = Sensrls Vect
1 = SV Economize
2 = Custom V/Hz
3 = Fan/Pmp-V/Hz
4 = FVC Vector
Default: 0 = Sensrls Vect
Access: 2 Path: Motor Control>Torq Attributes
See also: 80
