651 adj volt select, 652 adj volt ref hi, 653 adj volt ref lo – Rockwell Automation Liqui-Flo DBT Reach Drive User Manual
Page 151
Parameter Descriptions
3-125
Selects the source of the voltage reference to the drive.
Scales the upper value of the Adj Volt Select (651) selection when the source is in any
analog input.
Scales the lower value of the Adj Volt Select (651) selection when the source is in any
analog input.
651
Adj Volt Select
Range:
0 = Reserved
1 = Analog In 1
2 = Analog In 2
3-6 = Reserved
7-8 = Not Used
9 = MOP Level
10 = Reserved
11-17 = Preset Volt 1-7
18-22 = DPI Port 1-5
Default:
2 = Analog In 2
Access:
2
Path: Applications>Adjust Voltage
See also:
652
Adj Volt Ref Hi
Range:
-/+ 100.0% of Drive Rated Volts [0.1%]
Default:
100.0%
Access:
2
Path: Applications>Adjust Voltage
See also:
653
Adj Volt Ref Lo
Range:
-/+ 100.0% of Drive Rated Volts [0.1%]
Default:
100.0%
Access:
2
Path: Applications>Adjust Voltage
See also:
