Page 175: 541 encdlss ang comp
Parameter Descriptions
3-149
TBD
Integral gain for the Frequency Regulator.
Proportional gain for the Frequency Regulator.
Angle used to compensate for long cables attached to inverter and motor. Identified
during autotune for Encoderless FVC.
538
Rec Delay Time
Range:
1 to 30000 [1]
Default:
1000
Access:
2
Path: Utility>Diag-Motor Cntl
See also:
539
Ki Freq Reg
Range:
0 to 32767 [1]
Default:
450
Access:
2
Path: Utility>Diag-Vector Cnt
See also:
540
Kp Freq Reg
Range:
0 to 32767 [1]
Default:
2000
Access:
2
Path: Utility>Diag-Vector Cnt
See also:
541
Encdlss Ang Comp
Range:
-1023 to 1023 [1]
Default:
0
Access:
2
Path: Utility>Diag-Vector Cnt
See also:
