Parameter Descriptions 3-91
Assigns an input function to the drive’s digital inputs.
To access Preset Speed 1, set Speed Ref x Sel to Preset Speed 1.
48 =Set Home
49 = Find Home
50 = Home Limit
51 = Vel Override
52 = Pos Sel 1
53 = Pos Sel 2
54 = Pos Sel 3
55 = Pos Sel 4
56 = Pos Sel 5
57 = Prof Input
Default: See table 11.6
Access: 361= 0
362-366 = 1 Path: Inputs & Outputs>Digital Inputs
See also: 96, 100, 124, 140, 156, 162, 194, 380
1 When Digital lnx Sel is set to 2 = Clear Faults, the Stop button cannot be used to clear a fault condition.
2 Typical 3-wire Inputs: Only 3-wire functions are allowed. Including 2-wire selections will cause a type 2 alarm.
3 Typical 2-wire Inputs: Only 2-wire functions are allowed. Including 3-wire selections will cause a type 2 alarm.
361
362
363
364
365
366 Digital In1 Sel
Digital In2 Sel
Digital In3 Sel
Digital In4 Sel
Digital In5 Sel
Digital In6 Sel
Table 3.4 – Speed Select Inputs
Speed Select Inputs (17,16,15)
3 2 1 Reference Source
0 0 0 Reference A
0 0 1 Reference B
0 1 0 Preset Speed 2
0 1 1 Preset Speed 3
1 0 0 Preset Speed 4
1 0 1 Preset Speed 5
1 1 0 Preset Speed 6
1 1 1 Preset Speed 7
