Troubleshooting the Drive 13-19
Incorrect operation
from the terminal
block. (cont’d) Analog input does not work. See Anlg In Config (320).
Verify that correct
terminals are used for
configuration as voltage
input or current input.
Incorrect input logic wiring. See Dig In Status
diagnostic parameter
(216). Verify that the input
is detected properly.
Flashing yellow
Ready LED and
DigIn CflctB
indication on LCD
OIM.
Drive Status 2
(210) shows type 2
alarm(s).
Incorrect digital input
programming.
• Mutually exclusive
choices have been
made.
• 2-wire and 3-wire
programming may be
conflicting.
• Exclusive functions (i.e,
direction control) may
have multiple inputs
configured.
• Stop if factory default and
is not wired or is open.
• Start or Run
programming may be
missing.
Program Digital In”x” Sel
(361-366) to resolve
conflicts.
Remove multiple
selections for the same
function.
Install stop button to apply
a signal at stop terminal.
Check start inhibit status
in Start Inhibits (214).
Table 13.9 – Drive Does Not Start From Start, Run, or Jog Inputs Wired to the
Terminal Block (Continued)
Indication(s) Cause(s) Corrective Action
Table 13.10 – Drive Does Not Start or Jog From OIM
Indication Cause(s) Corrective Action
None Drive is programmed for
2-wire control and Logic
Source Sel (89) = All
Ports. OIM start and
network start are
disabled for 2-wire
control. If 2-wire control is
required, no action is
necessary.
If 3-wire control is
required, program Digital
In”x” Sel (361-366) for
correct inputs.
Flashing or steady red
Ready LED. Active fault. Reset fault.
