Starting Up the Drive Using the LCD OIM 10-3
You do not have to configure all of the parameters in all 7 menus.
The first menu selection, Quickstart, contains the minimum basic
parameters that must be configured before running the drive. These
parameters are listed in table 10.1.
The drive’s default configuration assumes the following:
• US Voltage Class (202)
• Motor Nameplate Base Freq (43) = 60 Hz
• Control Mode (53) = Sensorless Vector
Note: The default start/stop and reference control are configured for
OIM operation.
Logic and reference sources (89, 90) = Local OIM
If your application requires adjustment to parameters beyond those
listed in table 10.1, you can adjust parameters individually through
the Parameters menu (see section 11.3), or you can adjust the
parameters in any or all of the next 6 selections in the Start-Up
menu:
Input Voltages
• 400/480 V, 200/240 V, or 575 V
Motor Nameplate Data
• Motor Power Units
• Motor Power
• Motor FLA
• Motor Volts
• Motor Hertz
• Motor RPM
Motor Tests
• Direction
• Autotune
Table 10.1 – Quickstart Parameters
Parameter No. Parameter Name Default
155 Stop Mode A Ramp
42 Motor NP FLA Drive-dependent
81 Minimum Speed 0.0 Hz
82 Maximum Speed 60.0 Hz
140 Accel Time 1 10.0 sec
142 Decel Time 1 10.0 sec
90 Speed Ref A Sel OIM
362 Digital In2 Sel Start
