Installation Record D-1
A
PPENDIX
D
Installation Record
Record the switch settings for your setup in the diagrams below:
Model Number:
0 = 1500 RPM (50 Hz)
1 = 1800 RPM (60 Hz)(Default)
2 = 2100 RPM (70 Hz)
3 = 2400 RPM (80 Hz)
4 = 2700 RPM (90 Hz)
5 = 3000 RPM (100 Hz)
6 = 3300 RPM (110 Hz)
7 = 3600 RPM (120 Hz)
Accel/Decel Switch Max Speed Switch
Setup Slide Switch
(SW2) (SW1)
( SW3 )
0 = 1 sec accel / 5 sec decel
1 = 5 sec (Default)
2 = 10 sec
3 = 15 sec
4 = 20 sec
5 = 30 sec
6 = 60 sec
7 = 90 sec
Minimum Speed From Terminal Block Inputs
Reverse Disabled (Reverse Lockout)
Ramp-to-Rest Stop
0 Hz Minimum Speed
Reverse Enabled
Coast-to-Rest Stop
Analog Speed Reference From Terminal Block
Constant Torque Curve
Auto Restart Enabled
Power-Up Start Enabled
Relay Control Output: Faulted
1> Speed Reference From Operator Controls
Relay Control Output: Running
Power-Up Start Disabled
Variable Torque Curve
Auto Restart Disabled
Start from Terminal Block
Parameter Settings from EEPROM Memory
2
6
3
4
5
1
0
7
1> Start from Operator Controls
2> Parameter Settings from Setup Switches
2
6
3
4
5
1
0
7
1> Switches 2 and 9 apply only to local operator control units.
2> Switch 10 is used only with the DeviceNet Communication Option.
O N
1
23
45
6
7
89
10
