Page 71
Diagnostics and Troubleshooting
11-9
11.4 Replacement Part Compatibility
Table 11.10 – Replacement Bearings
Motor Frame
Part Number
Quantity
Description
56 or 140
416821-56-F
2
6205 ball bearings; double seals with
Chevron SRI #2 grease; ABEC 1
tolerances; AFBMA-3 internal
tolerances.
180 416821-56F
416821-56G
1
1
Table 11.11 – Replacement Part Compatibility
Replacement Part
VSM500
Description
Version
Version 1.0
Version 2.0
Version 3.0
Control Board Replacement Kit
1.0
Compatible
Not Compatible
Not Compatible
2.0
Not Compatible
Compatible
Not Compatible
3.0
Not Compatible
Not Compatible
Compatible
Cover with Display Only
1.0
Compatible
Compatible
Compatible
1
2.0
Compatible
Compatible
Compatible
1
3.0
Compatible
2
Compatible
2
Compatible
Cover with Display and Operator
Controls
1.0
Compatible
Compatible
Compatible
1
2.0
Compatible
Compatible
Compatible
1
3.0
Compatible
2
Compatible
2
Compatible
1
The DeviceNet Communication LED is not present on the Version 1.0 or 2.0 cover assembly.
2
The DeviceNet Communication LED will be illuminated while the unit is powered.
