11-8 Installing and Operating the VSM500 Integrated Drive/Motor, Version 3.0
Table 11.8 – Replacement Parts for 230 VAC Units
Replacement Part 1 HP Unit 2 HP Unit
Drive Section - 230 VAC, 3-Phase with Display 10XS2000 21XS2000
Drive Section - 230 VAC, 3-Phase with Operator
Controls 10XW2000 21XW2000
Drive Section - 230 VAC, 1-Phase with Display 10XS3000 21XS3000
Drive Section - 230 VAC, 1-Phase with Operator
Controls 10XW3000 21XW3000
Motor Section - 230 VAC, 1- and 3-Phase
NEMA 56 J56Z5211 -
Motor Section - 230 VAC, 1- and 3-Phase
NEMA 140 J14Z5211 J14Z5221
Blower 164454 164454
Blower Cover 164408 164408
Cover with Display (includes display cable) 194431 194431
Cover with Display and Operator Controls
(includes display cable) 194432 194432
Optional Short Cover with Display (includes
display cable)
1
1 The short cover cannot be used with the DeviceNet Communication option.
195083 195083
Optional Short Cover with Display and Operator
Control (includes display cable)
1
195084 195084
Regulator Board 194458 194458
Display Cable (Long) 184314 184314
Table 11.9 – Replacement Parts for 115 VAC Units
Replacement Part 1 HP Unit
Drive Section - 115 VAC, 1-Phase with Display 10XS1000
Drive Section - 115 VAC, 1-Phase with Operator Controls 10XW1000
Motor Section - 115 VAC, 1-Phase NEMA 56 J56Z5111
Motor Section - 115 VAC, 1-Phase NEMA 140 J14Z5111
Blower 164454
Blower Cover 164408
Cover with Display (includes display cable) 194431
Cover with Display and Operator Controls (includes display cable) 194432
Optional Short Cover with Display (includes display cable)
1
1
The short cover cannot be used with the DeviceNet Communication option.
195083
Optional Short Cover with Display and Operator Controls
(includes display cable)
1
195084
Regulator Board 194458
Display Cable (Long) 184314
