Wiring Requirements for the Drive 4-11
Table 4.5 – AC Line Input Fuse Selection Values
Model
Number
F
r
a
m
e
Output Amps Nominal Power Ratings
Dual
Element
Time
Delay
Fuse
Non-Time
Delay Fuse
Circuit
Breaker
575 VAC
110% OL
Duty
150% OL
Duty 575 VAC 575 VAC
575
VAC
Cont
1
Min
3
Sec kW HP kW HP Min Max Min Max A
-022xxxxx 2 22 25.5 34 15 20 11 15 30 50 30 80 80
-027xxxxx 2 27 33 44 18.5 25 15 20 35 60 35 100 100
-032xxxxx 3 32 40.5 54 22 30 18.5 25 40 70 40 125 125
-041xxxxx 3 41 48 64 30 40 22 30 50 90 50 150 150
-052xxxxx 3 52 61.5 82 37 50 30 40 60 110 60 200 200
-062xxxxx 4 62 78 104 45 60 37 50 80 125 80 225 225
-077xxxxx 5 77 85 116 55 75 - - 90 150 90 300 300
63 94 126 - - 45 60 90 125 90 250 250
-099xxxxx 5 99 109 126 75 100 - - 125 200 125 375 375
77 116 138 - - 55 75 100 175 100 300 300
-125xxxxx 6 125 138 188 90 125 - - 150 250 150 375 375
99 149 198 - - 75 100 125 200 125 375 375
-144xxxxx 6 144 158 216 110 150 - - 175 300 175 400 400
128 188 250 - - 90 125 150 275 150 375 375
