Rockwell Automation SP600 User Manual Version 3.0 User Manual
Page 185

Parameter Descriptions
11-83
361
362
363
364
365
366
Digital In1 Sel
Digital In2 Sel
Digital In3 Sel
Digital In4 Sel
Digital In5 Sel
Digital In6 Sel
Range:
0 = Not Used
1 = Enable
2 = Clear Faults
1
3 = Function Loss
4 = Stop - CF
2
5 = Start
6 = Fwd/Reverse
3
7 = Run
4
8 = Run Forward
4
9 = Run Reverse
4
10 = Jog
3
11 = Jog Forward
12 = Jog Reverse
13 = Stop Mode B
14 = Bus Reg Md B
15 = Speed Sel 1
5
16 = Speed Sel2
5
17 = Speed Sel 3
5
18 = Manual
19 = Reserved
20 = Acc2 & Dec2
21 = Accel 2
22 = Decel 2
23 = MOP Inc
24 = MOP Dec
25 = OIM Control
26 = PI Enable
27 = PI Hold
28 = PI Reset
29 = Pwr Loss Lvl
30 = Precharge En
31 - 38 = Reserved
39 = UserSetBit0
40 = UserSetBit1
Default:
See table 11.7
Access:
1
Path: Inputs & Outputs>Digital Inputs
See also:
96, 100, 124, 140, 156, 162, 194, 380
1
When Digital In”x” Sel is set to option 2 (Clear Faults), the stop key cannot
be used to clear a fault condition.
2
Stop -CF may be used for 2 wire functions. See #4 below.
3
Typical 3-Wire Inputs. These require that only 3-wire functions are chosen.
Including 2-Wire selections will cause a type 2 alarm.
4
Typical 2-Wire Inputs. These require that only 2-wire functions are chosen.
Including 3-wire selections will cause a type 2 alarm.
