Rockwell Automation 1794-APBDPV1 FLEX I/O PROFIBUS Adapter User Manual User Manual
Page 67
Publication 1794-UM064B-EN-P - May 2014
Communicate With Your Module 55
Setting the Input Filters
Bits
Channel
03
02
01
00
Input Channel 0
07
06
05
04
Input Channel 1
A/D Conversion Rate
Low Pass Filter
0
0
0
0
1200 Hz
No low pass
0
0
0
1
1200 Hz
100 ms low pass
0
0
1
0
1200 Hz
500 ms low pass
0
0
1
1
1200 Hz
1000 ms low pass
0
1
0
0
600 Hz
No low pass
0
1
0
1
600 Hz
100 ms low pass
0
1
1
0
600 Hz
500 ms low pass
0
1
1
1
600 Hz
1000 ms low pass
1
0
0
0
300 Hz
No low pass
1
0
1
0
300 Hz
100 ms low pass
1
0
1
1
300 Hz
500 ms low pass
1
1
0
0
300 Hz
1000 ms low pass
1
1
0
1
150 Hz
No low pass
1
1
1
0
150 Hz
100 ms low pass
1
1
1
1
150 Hz
500 ms low pass
150 Hz
1000 ms low pass
(2)
Configure Your Output Channels
Configuration Bits
MSD LSD
Nominal
Range
Data Type
Output Values
Hexadecimal Decimal
Update
Rate
0
0
0
1
4...20 mA
2’s complement
<0000...7878>
<0000...30840>
5.0 ms
0
0
1
0
± 10V
2’s complement
<8618...79E8>
<-31208...31208>
2.5 ms
0
0
1
1
± 5V
2’s complement
<8618...79E8>
<-31208...31208>
2.5 ms
0
1
0
0
0...20 mA
2’s complement %
<0...10000>
<0...10000>
5.0 ms
0
1
0
1
4...20 mA
2’s complement %
<0...10000>
<0...10000>
5.0 ms
0
1
1
0
0...10V
2’s complement %
<0...10000>
<0...10000>
5.0 ms
0
1
1
1
± 10V
2’s complement
<-10000...10000>
<-10000...10000>
5.0 ms
1
0
0
0
0...20 mA
binary
<0000...F3CF>
<0000...62415>
2.5 ms
1
0
0
1
4...20 mA
binary
<0000...F0F1>
<0000...61681>
5.0 ms
1
0
1
0
0...10V
binary
<0000...F3CF>
<0000...62415>
2.5 ms
1
0
1
1
0...5V
binary
<0000...F3CF>
<0000...62415>
2.5 ms
1
1
0
0
4...20 mA
offset binary
<8000...F9E8>
<32768...63976>
2.5 ms
