Page 103: Chapter 5, Overview status indicators, Chapter
91
Publication 1794-UM064B-EN-P - May 2014
Chapter
5
Interpret Status Indicators for the FLEX I/O
PROFIBUS Module
Overview
Read this chapter to troubleshoot your I/O module.
Status Indicators
1794-APBDPV1 Module
Locate the two bi-color indicators on the front panel of the adapter. They show
both normal operation and fault conditions in your FLEX I/O PROFIBUS
system. The indicators are:
• STATUS – this indicator provides device status
• PROFIBUS – this indicator provides communication link status
Use the following tables to determine the indicator conditions and status.
For Information On
See Page
View status from the Master’s Configuration Software
1121
Status indicator
PROFIBUS
indicator
