Publication 1794-UM064B-EN-P - May 2014
30 Communicate With Your Module
1794-IR8 Word/Bit Descriptions
Word Dec. Bits
(Octal Bits) Description
Write Word 0 00…01 Module Data Type
Bit 01 00
0 0 °C (default)
0 1 °F
1 0 Bipolar counts scaled between -32768... 32767
1 1 Unipolar counts scaled between 0...65535
02 Enhanced mode select – Measures voltage drop across a precision resistor in the module to compare
with the unknown input.
03…05 A/D Filter First Notch Frequency
Bit 05 04 03 Definition
0 0 0 10 Hz (default)
0 0 1 25 Hz
0 1 0 50 Hz
0 1 1 60 Hz
1 0 0 100 Hz
1 0 1 250 Hz
1 1 0 500 Hz
1 1 1 1000 Hz
06 Gain Offset Calibration – This bit is set during gain calibration/ reset during offset calibration.
07 Calibration Clock – This bit must be set to 1 to prepare for a calibration cycle; then reset to 0 to initiate
calibration.
08…15 Calibration Mask – The channel, or channels, to be calibrated will have the correct mask bit set. Bit 0
corresponds to channel 0, bit 1 to channel 1, and so on.
