Chapter 9

Printing Messages

9–6

For example, the following window shows file FILE2.KPD highlighted. To
accept the file, press [Enter].

The following keys are valid when selecting a file.

File

Selection Keys

Function

[

↑

] [

↓

]

Moves highlight up or down the list of file names.

[Home] or [End]

Moves highlight to first or last file name in list.

[PgUp] or [PgDn]

Moves highlight up or down one page in window.

[Enter]

Accepts file and opens Select File menu.

[Esc]

Closes File Selections window and returns you to menu.

After selecting a file, the software reads the file:

and opens this menu. The name of the selected file displays next to Print.

See the next section for details on printing messages.
