Chapter 9
Printing Messages
9–12
If the selected file does contain messages, the Message Selections/Message
Picks window opens displaying a list of all messages in the file with the first
message number highlighted. The Message Selections window lists the
numbers (in ascending order) of all messages in the file.
Select messages to print by moving numbers from the Message Selections
list to the Message Picks list. You can move a single message or a block of
messages. To move a single message, highlight the message number and
press [Enter]. To move a block of messages, refer to the table below.
Use the keys below to select messages for printing.
Message
Selection Keys
Function
[
→
] [
←
] Moves highlight between Message Selections list and Message Picks list.
[
↑
] [
↓
] Moves highlight up or down the list of numbers.
[Home] or [End] Moves highlight to first or last number in list.
[PgUp] or [PgDn] Moves highlight up or down one page in window.
[B] Start delimiter for selecting a block of messages. Press [B] on highlighted
number, then use arrow keys to include other numbers in the block. Press
[Enter] to move the block of messages to the Message Picks list.
To disable the block selection, press [B] again.
[Enter] Moves highlighted number or block of numbers to the Message Picks list
(or back to Message Selections list).
[F10] Accepts Message Pick list and starts printing messages.
[Esc] Exits window and returns to Select File menu.
