Chapter 6
Creating/Selecting a Message File
6–7
The directory in which the files are stored displays to the left. For each
message file, the window shows:
•
file name and extension (.KPD)
•
size of the file (in bytes)
•
date/time file was last created or modified
To select a file, highlight the file you want to edit and press [Enter]. You can
use the following keys to select a file from the File Selections window.
Key Function
[
↑
] [
↓
] Use arrow keys to move up or down the list of file names.
[Enter] or [F10] Selects highlighted file.
[Esc] Exits window and returns to Develop menu.
[Home] Moves highlight to first file name.
[End] Moves highlight to last file name.
[PgUp] [PgDn] Moves one page up or down in window.
For example purposes, let’s say you selected FILE2. After the following
messages display, the Messages menu opens.
For details on how to use functions on the Messages menu, see Chapter 7
Message Operations.
