Chapter 7
Message Operations
7–25
Entering the Start Value
To enter a start value for the renumber operation, highlight Starting Message
Location and press [Enter]. A three digit numeric field opens to the right.
Enter a start value between 1 and 120, then press [Enter]. The highlight
moves to Increment.
For example, enter 20 to renumber message 1 to 20. If renumbering
multiple messages, the renumber operations starts at 20.
If you do not change the value from 0 or enter a value greater than 120, this
message displays:
Use the keys below to enter start and increment values for a renumber
operation:
Start and
Increment Keys
Function
0–9 Enters a numeric value in the range of 0 to 9.
[BackSpace] Deletes character to left of cursor.
[
↓
] Moves highlight down one menu function. If cursor is in numeric field, [
↓
]
accepts start or increment value.
[
↑
] Moves highlight up one menu function. If cursor is in numeric field, [
↑
]
accepts start or increment value.
[Del] Deletes character at cursor.
[Enter] Selects highlighted menu function or if in numeric field accepts start or
increment value
[Esc] If menu option is highlighted, exits to Renumber Message menu.
If numeric field is highlighted, [Esc] exits field (resetting to initial value) and
moves to next menu option.
