9 - printing messages, Chapter objectives, Connecting to a printer – Rockwell Automation 2705-ND1 Keypad Development Software User Manual
Page 90: Printing messages
A–B
9
Chapter
9–1
Printing Messages
This chapter shows how to use the Report function to:
•
Select a message file to print
•
Select and configure a printer port
•
Select messages in the file to print
•
Printing messages
Before you can print messages, you must connect your computer to a printer
using the appropriate communications cable.
One end of the cable will connect to a communication or printer port on your
computer and the other end will connect to a port on the printer.
The software uses LPT1 as the default printer port. This printer port does not
require that you set any communication parameters.
communications cable
Note: The printer cable is not included in the Keypad Development
Software package.
Chapter Objectives
Connecting
to a Printer
