4 - getting started, Chapter objectives, Running the software – Rockwell Automation 2705-ND1 Keypad Development Software User Manual
Page 18: Getting started
A–B
4
Chapter
4–1
Getting Started
This chapter provides some helpful hints on how to use the software,
including:
•
Running the software
•
Pop-up menus, windows, and highlight
•
Selecting menu options
•
Getting help
•
Warning, error and program status messages
•
Exiting the software
•
Menu tree structure
To access the software, make sure that you are located in the default program
directory (created during installation). All examples in this manual assume
that you installed the software on a hard disk and show C:\KEYPAD> as the
program directory. Your DOS prompt may be different.
Run the software by typing KEYPAD and pressing [Enter]. The copyright
screen then displays.
C:\KEYPAD> keypad [Enter]
Press any key to access the main menu.
Chapter Objectives
Running the Software
