Chapter 8
Downloading Messages
8–3
To access functions which allow you to download messages from your
computer to the Keypad Module, select Transfer from the main menu.
Highlight Transfer, then press [Enter] or just press [T]. The Transfer menu
displays with Download to Keypad Module highlighted.
Figure 8.2
Transfer Menu
The Transfer functions are:
Download to Keypad Module
Accesses a menu which allows you to select a file
for downloading. Another menu then opens which
allows you to download messages.
Terminal/Keyboard Mode
Enters keyboard emulation mode, allowing you
to operate your computer keyboard with the
Keypad Module.
Configure Port Selects a communication port on your computer
for the download operation. COM1 is the default.
Quit Exits and returns to the main menu.
Transfer Menu
