Chapter 4
Getting Started
4–3
You can select a menu option in one of two ways:
1. Highlight an option using the arrow keys and press [Enter].
2. Type the first letter of a menu option.
For example, to select Develop press the [D] key. The menu opens
immediately (without pressing [Enter]).
Note: If a menu lists several options starting with the same letter, typing
the first letter always selects the first menu option (not the second).
Table 4.A lists keys that are used to select menu options and window items.
Table 4.A
Menu / Window Control Keys
Key Function
[
↑
] [
↓
] [
→
] [
←
] Use arrow keys to move through menu options and window items.
[SpaceBar] Moves through menu options and window items.
[Enter] or [
↵
] Selects highlighted menu option or window item.
[Esc] Exits menu or window and returns to previous menu.
[Home] Moves highlight to first menu or window item.
[End] Moves highlight to last menu or window item.
[PgUp] [PgDn] Moves one page up or down in window displays.
Table 4.B lists keys that are used for data entry functions.
Table 4.B
Data Entry Keys
Key Function
[
→
] [
←
] Moves cursor to right or left.
[Enter] or [
↵
] Accepts entry.
[BackSpace] Deletes character to left of cursor.
[Del] Deletes character at cursor.
[Ins] Toggles editing between insert and overstrike mode.
[Esc] Aborts data entry window or field without saving changes.
[F3] Cancels any changes and resets field or window to previous state.
[F5] Clears data field.
[F6] Clears to end of data field.
[F7] Moves cursor to beginning of field.
[F8] Moves cursor to end of field.
[F10] Saves data and returns to previous menu.
Selecting Menu Options
Menu Control Keys
Data Entry Keys
