4-50 Commissioning
7000A-RM001A-EN-P – January 2011
7000 “A” Frame
System Test (cont.)
Start/Stop Control Circuit
Once the drive is in System Test mode, ensure that the stop/start
circuit functions as desired. It may be necessary to study the
electrical schematic drawings, prior to performing this test, in order
to understand the control circuit.
Start the drive in local control while observing the system vacuum
contactors or customer supplied circuit breakers. If troubleshooting is
required in Rockwell Automation medium voltage switchgear,
additional information is available in the following publications:
•
Publication
1500-UM055_-EN-P, Medium Voltage Controller,
Bulletin 1512B, Two-High Cabinet, 400 Amp • User Manual
•
Publication
1503-IN050_-EN-P, OEM Starter Frame and
Components • Installation Manual
•
Publication
1502-UM050_-EN-P, Medium Voltage Contactor,
Bulletin 1502, 400 Amp (Series D) • User Manual
•
Publication
1502-UM052_-EN-P, Medium Voltage Contactor,
Bulletin 1502, 400 Amp (Series E) • User Manual
•
Publication
1502-UM051_-EN-P, Medium Voltage Contactor,
Bulletin 1502, 800 Amp • User Manual
If the Medium Voltage contactors or circuit breakers perform as
desired, stop the drive and perform the same test while operating in
remote control.
Start the drive again and verify that all emergency stops installed in
the system function as desired. Ensure that all electrical interlocks
installed in the system function as desired. Make any necessary
control wiring modifications at this time and re-test the system if
necessary.
Status
Indicators
Drive status is often feedback to a plant’s process control either
digitally through the PLC input/output feature (see Chapter 3 –
Operator Interface, PLC page 3-43) or through relay logic. The
following relays are provided with the drive as standard:
Relay Name
Relay Designation
Run Contact
Fault Contact
Warning Contact
Ready Contact
RUN
FLT
WRN
RDY
