6
Setup, Programming, and Troubleshooting
DNI Software Files To configure the DNI as an I/O slave device on a DeviceNet network,
you may need to obtain two software files. These two files provide
your network configuration software with the information it needs to
interface with the DNI.
DNI Series A Information
RSNetWorx and DeviceNet Manager (version 3.0 and higher) include
the files necessary for DNI Series A.
DNI Series B Information
To configure the Series B DNI, you must have the Series B DNI EDS
file installed in your DeviceNet configuration software. RSNetWorx
DeviceNet Network Management software version 2.11.36 or higher
includes all Series B DNI files. You can also download the new files
from http://www.ab.com/micrologix.
The following table shows the old and new file filenames:
Series B DNI Files
1761-NET-DNI File Description File Name
Series B DNI Electronic Data Sheet 1761DNI3.EDS
DNI Configuration Software Utility DNIUTIL1.EXE (Rev. 2.0 or higher)
DNI Icon for Configuration Software 1761DNI.ICO or 1761DNIB.BMP
Series A DNI Electronic Data Sheet 1761DNI2.EDS
DNI Configuration Software Utility DNIUTIL1.EXE
DNI Icon for Configuration Software 1761DNI.BMP
ATTENTION
DNI Series A configurations are not compatible with
DNI Series B. You must manually re-enter the Series
A parameters into the Series B DNI. This step is
required because of the enhanced functionality of
DNI Series B.
