38 DNI Configuration Parameters and Programming Notes
The DNI’s output image will consist of:
The minimum value allowed for the Split Point is 1. If the Output Size
is 32 (maximum), the resulting range of explicit output words would
be 0x90 to 0xAE.
See Output Assembly Data (Explicit, Split Point, and Slave) on page 68
for more information.
Output Type
This parameter is used to identify the type of data to be written to the
controller. The DNI supports data exchange with either bit or integer
files.
DNI’s Output Image
Word Instance ID
0 Master’s Slave Data and Status 0x65
1 Master’s Slave Data
2 ↓
3 Master’s Slave Data
Split Point
4
Explicit Output Data 0x90 You can use
0x67 to access
the entire
configured
explicit
assembly.
5 ↓ 0x91
6
↓
0x92
9
↓
0x93
8 ↓ 0x94
9 ↓ 0x95
10
↓
0x96
11
↓
0x97
12 ↓ 0x98
13 ↓ 0x99
14
↓
0x9A
15
↓
0x9B
16 ↓ 0x9C
17
↓
0x9D
18 Explicit Output Data 0x9E
Parameter
Type Parameter number Description Range Default
Value
Series A Series B
I/O 9 8 Output Type Bit or Integer File Integer File
