14 Quick Start
To configure a MicroLogix 1000 controller as a slave device to a
DeviceNet master, set the parameters as shown in the following table.
MicroLogix 1000 Controller Parameter Settings
Parameter Number
Description
Range
Default Value
For this Example,
ENTER
Series A
Series B
4
1
Input Size
Series A: 1…16
Series B: 1…32
1 word
2 words
Not Applicable
2
Input Split Point
1…32
1 word
2 words
5
3
Input Type
Bit or Integer File
Integer File
Integer File
6
4
Input Data File
3…254
7
7
7
5
Input Word Offset
0…254
0
90
8
6
Output Size
Series A: 1…16
Series B: 1…32
1 word
2 words
9
8
Output Type
Bit or Integer File
Integer File
Integer File
10
9
Output Data File
3…254
7
7
11
10
Output Word Offset
0…254
1
95
14
11
DF1 Device
0…3:
0: Other
1: PLC
2: SLC/ Other
MicroLogix
3: MicroLogix 1000
3 = MicroLogix 1000
3 = MicroLogix 1000
3
12
DNI Series A:
Data Enable
DNI Series B:
I/O Scan Enable
(Polling Enable)
Disabled (0) or Enabled
(1)
Disabled (0)
Enabled (1)
12
13
DF1 Heartbeat
Series A: 2…10
Series B: 1…10
2
2
13
14
Data Scan Delay
(Polling Delay)
20…3000 ms
50 ms
100 ms
2
15
Message Timeout
0…2500 ms
0 ms
0 ms
Not Applicable
16
DF1 Substitute Address
0…64
64 = Disabled
64 = Disabled
15
17
DF1 Autobaud
Disabled (0) or Enabled
(1)
Enabled (1)
Enabled (1)
16
18
DF1 Baud Rate
0…5:
0: 38,400
1: 19,200
2: 9600
3: 4800
4: 2400
5: 1200
Series A: 2 = 9600
Series B: 1 = 19,200
n/a
1
19
DeviceNet Autobaud
Disabled (0) or Enabled
(1)
Enabled (1)
Enabled (1)
17
Not
Applicable
DNI Mode
Standby (0) or
Operational (1)
Operational (1)
Operational (1)
