DNI Configuration Parameters and Programming Notes 41
Device Type
Select the device connected to the DNI’s RS-232 port. If you are
connecting an Allen-Bradley controller as a DeviceNet I/O slave
device, this selection is used by the DNI to determine the type of
communication commands used to read and write data.
To achieve the best communications performance you should use
these recommended combinations.
I/O Scan Enable
This parameter enables the DNI to scan/exchange I/O data with DF1
devices. If the DNI is being used in an application that does not use
this feature, disabling this parameter improves the DNI’s messaging
Device Type Parameter Definition
Parameter
Type Parameter Number Description Range Default
Value
Series A Series B
I/O 14 11 DF1 Device 0…3:
0: Other
1: PLC
2: SLC/ Other
MicroLogix
3: MicroLogix
1000 3 = MicroLogix
1000
Recommended Combinations
RS-232 Device DF1 Device
Value File Type File Number
MicroLogix 1000 3 N (integer) 7
SLC 5/03 or higher
Other MicroLogix (MicroLogix 1500) 2 N (integer) 9
TIP
If you do not want to communicate with these
specific data files, RS-232 port communications
throughput will suffer marginally.
Parameter
Type Parameter Number Description Range Default
Value
Series A Series B
I/O 3 12 DNI Series A:
Data Enable
DNI Series B:
I/O Scan Enable
(Polling Enable) Disabled (0) or
Enabled (1) Disabled (0)
