Rockwell Automation 1785-LTx,D17856.2.1 Classic PLC-5 Programmable Controllers Users Manual User Manual
Page 60
Choosing Communication
Chapter 5
5-2
Figure 5.1
Processor Front Panels
P
R
O
G
PLCĆ5/10 Processor
PLCĆ5/12, Ć5/15,
and Ć5/25 Processors
Communication
Indicator
ACTIVE/FAULT
(green/red)
Keyswitch
Connect
programming
terminal here
Connect
DH+
link here
REM I/O Indicator
ACTIVE/FAULT
(green/red)
Adapter
Indicator
(green)
Connect
remote
I/O link here
Battery
Indicator (red)
Processor
RUN/FAULT
Indicator
(green/red)
FORCE
Indicator
(amber)
Write the DH+
network station
number on this label
PLCĆ5 family
member
designation
Battery Holder
Connector Name
Connector
Type
Description
Programming terminal
9Ćpin, DĆshell Use this connector to directly connect a programming terminal to the processor. This programming
terminal connector has a parallel connection with the 3Ćpin DH+ communications link connector.
DH+ communications link
3Ćpin
Use this connector to connect to DH+ communications link.
Remote I/O
3Ćpin
Use this connector for the remote I/O link. (This connector is not available for a PLCĆ5/10 processor.)
