Rockwell Automation 1785-LTx,D17856.2.1 Classic PLC-5 Programmable Controllers Users Manual User Manual
Page 143
Selecting Switch Settings
Appendix A
A-5
Remote I/O Adapter Module (1771ĆASB Series C) I/O Rack
NumberĊwithout Complementary I/O
Rack
1
2
3
4
5
6
01
on
on
on
on
on
off
02
on
on
on
on
off
on
03
on
on
on
on
off
off
04
on
on
on
off
on
on
05
on
on
on
off
on
off
06
on
on
on
off
off
on
07
on
on
on
off
off
off
10
on
on
off
on
on
on
11
on
on
off
on
on
off
12
on
on
off
on
off
on
13
on
on
off
on
off
off
14
on
on
off
off
on
on
15
on
on
off
off
on
off
16
on
on
off
off
off
on
17
on
on
off
off
off
off
20
on
off
on
on
on
on
21
on
off
on
on
on
off
22
on
off
on
on
off
on
23
on
off
on
on
off
off
24
on
off
on
off
on
on
25
on
off
on
off
on
off
26
on
off
on
off
off
on
27
on
off
on
off
off
off
PLCĆ5/15 processorsĊracks 01Ć03;
PLCĆ5/25 processorsĊracks 01Ć07;
