Dh+ specifications-link communication rate – Rockwell Automation 1784-PCMK PCMK Communication Card Installation Manual User Manual
Page 80
A-4 Specifications
Publication 1784-UM519C-EN-P - September 2006
DH+ Specifications-link Communication Rate
Allen-Bradley has added 230 Kbps communication rate enhancements to the DH+
binary.
Note this update to link communication rate in the DH+ memory map.
:007h
Link
Communication
Rate
INI
FCh = 57600
FEh = 230400
R...........W
Host writes a valid value (PCMK
communication rate) to
byte:00007h. PCMK reads at
startup.
IMPORTANT
Check the product documentation for your communication
software to see if the product supports 230 Kbps communication
rate.
