Rockwell Automation 1784-PCMK PCMK Communication Card Installation Manual User Manual
Page 57
Insert and Remove the PCMK Card 6-3
Publication 1784-UM519C-EN-P - September 2006
2. Grasp the PCMK card by the edges with the PCMK logo facing upward and
the 68-pin connector facing into the PCMCIA slot.
3. Insert the PCMK card into the PCMCIA slot and slide it in until firmly seated
in the connector. Some computers have an ejector button that pops out
when the card is seated in the connector.
IMPORTANT
If you have more than one slot in your computer, you can
insert the PCMK card into any empty slot. Check your
computer’s documentation for the slot numbers. The other
available slots can be used for other PC cards such as network
or modem cards.
30370
19873
